MicroVM

Experimental. Local Go Gateway and CLI VM sandboxes are available on Apple silicon with Hypervisor.framework. Linux KVM and installed release bundles remain validation gates. See the local VM quickstart and runtime acceptance matrix.

Current implementation

The driver creates one libkrun VM per sandbox. It can import a Linux rootfs from an OCI registry reference or a staged tar archive, build an immutable ext4 base image, and give each sandbox a writable overlay. Registry references use the host Docker/Podman credential keychain, including Docker credential helpers. The selected image platform is linux/<host-architecture>; manifest and layer digests are checked before the rootfs enters the cache. Layer application preserves setuid, setgid and sticky permission bits in addition to regular permissions.

The driver also has an authenticated guest control channel using versioned v1 JSON over length-prefixed frames; host and guest reject missing or unsupported versions. After the guest hardening step drops workload privileges, cautem-init reports its effective UID:GID through the supervisor readiness handshake. The VM driver persists that observed identity and Gateway Get/List responses expose it as the OpenShell WorkloadIdentity condition. start-workload returns only after the guest agent observes a private, versioned readiness marker written by the supervisor after it starts the workload. The marker path is removed from the child workload environment. The host rotates the per-sandbox token on each successful Start or recovery. Rotation state is kept in the private sandbox directory, and a retry after a lost response reuses the same rotation ID. The channel also provides process restart, exec, logs, file copy, policy proxy and SSH relay. The SSH relay carries OpenSSH direct-tcpip channels to guest loopback; macOS ARM64 live acceptance round-trips data through a TCP server inside the guest. Exec supports bounded one-shot commands and a full-duplex PTY session with stdin, window resize and terminal-generated signals. The Gateway compatibility adapter has a separate VM interactive-exec path. Its VM workspace request uses the persistent guest overlay and does not pass a host directory. Gateway sandbox creation passes local macOS ARM64 acceptance. This does not yet establish Linux KVM or installed-release support. The image rootfs is cached under the VM state directory. The default cache quota is 64 GiB; unreferenced images are reclaimed when more space is needed.

Production readiness

The Linux worker now starts in private user and mount namespaces and makes mount propagation private before creating its broker or VM. Startup fails when those namespaces cannot be established or when the Gateway itself runs as host root. The worker's namespace root still maps to the Gateway account; this is not a dedicated host UID. macOS launches a separate worker process. Neither platform receives a host workspace mount; the VM's writable ext4 overlay provides persistent workspace storage, matching the OpenShell VM model. The Gateway request builder expresses this storage mode, and local Gateway VM lifecycle acceptance passes on macOS ARM64.

Gateway VM create requests pass local macOS ARM64 acceptance. Linux KVM, installed release bundles and the broader host matrix remain release gates.

OCI image Entrypoint, Cmd, Env, User and WorkingDir are applied to the in-memory VM workload spec. Gateway recovery reloads the image config by the pinned platform manifest digest. The driver keeps image environment and user values out of durable state, filters reserved identity variables, and rejects root identities. Unit tests and macOS ARM64 live acceptance cover OCI config, private-registry credential-helper auth, digest-pinned recovery, one-shot TTY exec and image env/workdir inheritance. The same live run covers PTY resize, stdin and Ctrl-C delivery. Linux KVM acceptance, broader host supervisor/isolation coverage, GPU passthrough and PID limits remain open. These gaps are tracked in the runtime acceptance matrix.

Host setup

Build the worker, static Linux guest agent, umoci and runtime helpers with quarshell-driver/scripts/build-vm-runtime.sh. Set CAUTEM_VM_WORKER, CAUTEM_VM_GUEST_AGENT and OpenShell's OPENSHELL_VM_RUNTIME_DIR for the target host. VM state defaults to $XDG_STATE_HOME/openshell/vm-driver (or $HOME/.local/state/openshell/vm-driver); set OPENSHELL_VM_DRIVER_STATE_DIR to override it. Rootfs tar uploads stage under <state_dir>/rootfs-tar-staging by default; set rootfs_tar_staging_dir or OPENSHELL_VM_ROOTFS_TAR_STAGING_DIR to choose another directory. When OPENSHELL_VM_RUNTIME_DIR is unset, the Go driver looks for the runtime bundle under $XDG_DATA_HOME/openshell/vm-runtime (or $HOME/.local/share/openshell/vm-runtime). The bundle still must be installed by the operator; unlike upstream's embedded build resources, this Go build does not yet embed or extract libkrun. The build uses umoci v0.6.0 and verifies its SHA-256 against quarshell-driver/scripts/vm-runtime-artifacts.lock. Add a verified digest to the lock before selecting another version. A custom CAUTEM_VM_UMOCI binary requires CAUTEM_VM_UMOCI_SHA256; the binary is verified before publication to the runtime directory. A complete build writes vm-runtime-manifest.json with hashes for all seven artifacts; verification rejects missing, changed and unexpected files. Linux requires readable and writable /dev/kvm; macOS support targets Apple Silicon with Hypervisor.framework. Gateway preflight verifies the macOS worker signature and requires either a trusted Team ID or CAUTEM_VM_WORKER_SHA256 matching the ad-hoc-signed local worker. Rootfs preparation also requires e2fsprogs.

For two-disk Create, the host stages tar or OCI layout onto a temporary ext4 disk, launches the image-prep worker on the pinned bootstrap, and verifies /image-rootfs before publishing an immutable workload cache entry. This passes live macOS ARM64 acceptance; Linux KVM lanes and the complete failure/security matrix remain release gates.

Set CAUTEM_VM_IMAGE_CACHE_MAX_BYTES to change the default 64 GiB image cache quota. Registry credentials come from the Docker or Podman credential files available to the driver process. Uploaded rootfs tar files are limited to 10 GiB compressed and 32 GiB expanded.

For live driver acceptance, follow the VM section in the driver README. The compact VM sandbox quickstart covers local Go setup on macOS and Linux.

See the MicroVM pre-release plan for the full parity backlog, production phases, test matrix, and release criteria.
