Architecture and module boundaries

The responsibility of every independent module is listed in Project modules.

The accepted decision that governs these contracts is recorded in ADR 0001: Domain model and compute backend SPI.

Quarshell is the product name. Active Go module paths use the quarshell-* namespace; the cautem executable name is retained as a product command.

flowchart LR
    cli["CLI and terminal TUI"] --> sdk["Go / Python SDK"]
    ui["Browser UI"] --> ts["Typed HTTP / gRPC client"]
    sdk --> api["OpenShell Gateway API"]
    ts --> api
    api --> domain["Domain and orchestration"]
    domain --> spi["Compute backend SPI"]
    spi --> docker["Docker Backend"]
    spi --> podman["Podman Backend"]
    spi --> vm["MicroVM Backend"]
    domain --> state["Durable state and secret references"]
    docker --> runtime["Sandbox runtime"]
    podman --> runtime
    vm --> runtime
    runtime --> proxy["Policy and credential broker"]

Ownership and dependency direction

Module	Owns	May depend on
quarshell-core	Domain values, policy, validation, typed errors, capability definitions	Standard library and small domain utilities
quarshell-proto	Pinned OpenShell protocol sources and generated Go, Connect, and TypeScript bindings	Schema tooling
quarshell-driver	Compute SPI and Docker, Podman, MicroVM implementations	Core, runtime asset contracts, engine clients
quarshell-runtime	Guest init, supervisor, SSH/PTY, guest protocol	Core and runtime assets
quarshell-proxy	Egress enforcement, credential mediation, audit	Core policy and runtime protocol
quarshell-providers	Provider profiles, credential declarations, refresh validation	Core policy
quarshell-gateway	API composition, auth, durable state, operation orchestration	Core, proto, driver, runtime, proxy, providers
quarshell-sdk and quarshell-python	Typed API clients and streaming helpers	Public API schemas
quarshell-cli	Commands, terminal presentation, shell completions	SDK and terminal libraries
quarshell-ui	Browser presentation and browser-safe client	Typed browser client and gateway API
quarshell-display, quarshell-slogx, quarshell-docs	Display, logging utility, documentation	Their narrow public inputs

The dependency flow is one way: API clients call the gateway; the gateway selects and validates a backend; backend implementations use the runtime and host engine. Gateway code does not import CLI or UI packages. The CLI may keep its terminal TUI as a presentation package and use the SDK for operations. The browser UI uses a typed API client and never launches the CLI or imports its internal packages.

The browser console lives in the separate quarshell-ui module. It uses the generated OpenShell Gateway client and does not launch or import the CLI. The CLI ships commands and a terminal TUI; it does not ship a second HTTP browser app.

This boundary follows the public integration surfaces of current developer tools. OpenShell v0.1.4 separates its CLI, SDK, server and compute driver crates. Cursor documents its editor Agent and a CLI with interactive and non-interactive modes; the CLI supports the editor's modes, while the docs do not claim both clients share an internal API. OpenAI publishes Codex CLI, SDK and app-server integrations: the SDK serves programmatic tasks, while app-server exposes thread, turn, event and approval flows to an application that owns its interface and workflow. This evidence supports keeping Quarshell CLI and browser UI as separate clients of a shared public API. It does not establish private implementation details for Cursor or Codex. See the Cursor Agent overview, Cursor CLI overview, and Codex app-server integration guidance.

Compute backend SPI

quarshell-driver/driver/backend.go introduces the product-owned Backend SPI. Its request separates workspace, workload, resource limits, mounts, network, runtime assets and backend-owned typed configuration. The base interface owns create validation and lifecycle operations. Optional interfaces include InteractiveExec, LogAccess, FileTransfer, ServiceForward, RootfsImporter, CredentialRotator, RuntimeTokenStarter, RuntimePolicyUpdater, RuntimeLaunchSpecRestorer, RuntimeCredentialRefresher, RuntimeContractValidator, RuntimeProxyReadiness, RuntimeProcessWaiter, RuntimeProcessLogs and RuntimeProcessTerminal, and RuntimeRootfsTarStager. RequireExtension[T] checks both the advertised capability and the implemented method, returning UnsupportedError on either mismatch. Orchestration can validate a create request before it writes durable state or consumes a one-use upload.

All built-in implementations register the modular contract directly. The Gateway resolves only native Backend factories and remote OpenShell ComputeDriver protocol clients; it has no local Engine factory or fallback. Docker, Podman, Kubernetes and VM own their typed create inputs and optional extensions. The VM runtime still fails closed until its host supervisor and isolation lifecycle meet the Gateway contract.

New implementations can register the product contract directly. The Gateway resolves only the registered native Backend factory. A registered factory error is returned directly. Each backend uses its own typed startup config and optional extensions:

func RegisterCustomVM() error {
    return driver.RegisterBackendWithConfig("custom-vm", func(raw map[string]any) (driver.Backend, error) {
        config, err := parseCustomVMConfig(raw)
        if err != nil {
            return nil, err
        }
        return customvm.NewBackend(config), nil
    })
}

type customVMBackend struct {
    config customvm.Config
}

func (b *customVMBackend) ID() driver.BackendID { return "custom-vm" }

func (b *customVMBackend) Capabilities(context.Context) (driver.BackendInfo, error) {
    return driver.BackendInfo{
        ID: b.ID(),
        Capabilities: map[driver.Capability]struct{}{
            driver.CapabilityInteractiveExec: {},
            driver.CapabilityFileTransfer: {},
        },
    }, nil
}

// Implement ValidateCreate, Create, Start, Stop, Delete, List and Inspect.
// Implement driver.InteractiveExec and driver.FileTransfer only when those
// capabilities have a real, tested implementation.

The factory key is the backend ID and its returned Backend.ID() must match that key. Configuration is parsed once when the configured backend is first selected. Gateway maps the pinned OpenShell request into the domain BackendCreateRequest once at the protocol boundary; each backend then handles that modular request directly. Product-owned extension interfaces cover runtime validation, token-aware start, policy delivery, launch-spec restoration, credential refresh and proxy readiness directly on the modular Backend. BackendInfo.Resources can also report portable CPU, memory and GPU request support. Built-in Backend registration includes a static BackendInfo snapshot, so GetGatewayInfo reports local capabilities before a lazy Backend is created. Extensions registered without static metadata are reported after their Backend has already been initialized. Capabilities is static metadata and must not initialize a runtime or perform network I/O. Secret values in runtime or proxy inputs are short-lived request data and must never be copied into durable create records.

The core OpenShell extension negotiation helper checks protocol major versions and family-specific contract capabilities. Both peers must require and support openshell.<family>.contract; unknown families and incomplete metadata are rejected. RPC consumers still need to wire in this helper and prove that advertised operations pass backend acceptance.

Gateway resolves only registered native SPI backends for create preflight, create, start, stop, delete, create rollback, runtime reconciliation and sandbox recreation. Remote compute plugins use the same Backend contract. RuntimeLaunchSpecRestorer restores process-local workload settings after a Gateway restart; RuntimeCredentialRefresher refreshes credentials through an explicit Kubernetes capability; RuntimeContractValidator gates VM create on its Gateway requirements. RuntimeProxyReadiness handles the VM and Kubernetes proxy readiness check, while local containers use base Backend.Inspect. Docker and Podman expose canonical process wait, logs and terminal attachment through separate process extensions. Rootfs tar staging is dispatched through RuntimeRootfsTarStager and CapabilityRootfsTarStaging. VM non-TTY exec uses the InteractiveExec extension after checking the backend's declared capabilities. Restart uses the optional RuntimeTokenStarter extension when the backend explicitly advertises CapabilityTokenAwareStart; Kubernetes declares this capability, and the adapter forwards only to its token-aware lifecycle method:

starter, err := driver.RequireExtension[driver.RuntimeTokenStarter](
    ctx, backend, driver.CapabilityTokenAwareStart, "restart with a fresh token",
)
if err == nil {
    err = starter.StartWithToken(ctx, sandboxID, freshToken)
}

policyUpdater, err := driver.RequireExtension[driver.RuntimePolicyUpdater](
    ctx, backend, driver.CapabilityPolicyUpdate, "deliver a runtime policy update",
)
if err == nil {
    err = policyUpdater.UpdateSandboxPolicy(ctx, sandboxID, effectivePolicy)
}

credentialRefresher, err := driver.RequireExtension[driver.RuntimeCredentialRefresher](
    ctx, backend, driver.CapabilityCredentialRefresh, "refresh runtime credentials",
)
if err == nil {
    err = credentialRefresher.RefreshRuntimeCredentials(ctx, sandboxID)
}

platformWatch, err := driver.RequireExtension[driver.PlatformEventStream](
    ctx, backend, driver.CapabilityPlatformEvents, "watch platform events",
)
if err == nil {
    events, err := platformWatch.WatchPlatformEvents(ctx, driver.PlatformEventWatchRequest{
        SandboxID:   sandboxID,
        SandboxName: sandboxName,
    })
    if err == nil {
        for result := range events {
            if result.Err != nil {
                break
            }
            // Handle result.Event.
        }
    }
}

PlatformEventStream carries backend-native observations without claiming a durable cursor. The remote ComputeDriver Backend converts the pinned watch RPC into product-owned event values at the protocol boundary; protobuf types do not enter the watch handler. Backends that can guarantee resumable generation and sequence semantics should implement EventStream instead. Docker and Podman adapt Engine container events to this stream, filtered by the immutable container ID. These events have no durable cursor; Gateway's persisted lifecycle observations remain a separate source.

Kubernetes declares CapabilityTokenAwareStart, CapabilityPolicyUpdate, CapabilityCredentialRefresh and CapabilityProxyReadiness; VM declares CapabilityGatewayRuntimeValidation, CapabilityProxyReadiness and CapabilityRootfsTarStaging. Docker and Podman declare process wait/log/terminal capabilities. Gateway requires the policy capability before delivering an update to its remote runtime; local container backends continue to use the shared policy file. Runtime reconciliation, sandbox recreation and launch-spec restoration use the base SPI and its declared extensions. Built-in backend dispatch is modular; full parity remains open for VM host-supervisor/isolation acceptance and removal of the unused flat driver API.

Protocol compatibility boundary

The generated OpenShell Gateway server maps the pinned upstream protobuf contract to Quarshell domain operations. Upstream package and service names remain intact on that wire endpoint. Quarshell-owned domain types, configs, logs, CLI help and new APIs use Quarshell names. Generated protocol packages, wire identifiers, license attribution, pinned source and compatibility fixtures retain upstream names where the contract requires them.

The comparison baseline is OpenShell v0.1.4 at commit 5a7728c304b5528e954e9ae900cf21f84e1a12b1. It contains 83 methods in the public service and adds provider-label filtering, operator-only credential export and stable-placeholder negotiation. A method being registered is not proof of behavioral compatibility. See the compatibility register and runtime acceptance matrix.

Runtime path

1. The CLI or browser client sends a typed API request to the gateway.
2. The gateway authorizes the workspace, resolves policy and provider references, selects a backend, and validates supported fields.
3. The backend creates the sandbox and any required runtime resources.
4. The runtime reports readiness and policy state to the gateway.
5. Network requests pass through the policy enforcement path; credential material is released only when the runtime can enforce the matching endpoint binding.

Docker and Podman have broader lifecycle coverage than MicroVM. MicroVM Gateway creation remains fail-closed until the host isolation, image import, recovery and target-host acceptance gates pass. Kubernetes, browser UI feature completion and other remaining features are tracked in the internal second implementation plan.
